Distributor for buildings
2 HD threads
6 groups of 2 HD threads
Powers devices to 2 HD wires
Cascading of hubs
| Brand | Hikvision |
| Model | DS-KAD7060EY |
| Operation mode | Power, video and audio via 2 HD wire technology |
| Outputs | 2 channels of 2 HD threads with 15 W max. of power each 4 channels of 2 HD threads with 110 W max. of power between the four |
| Cascade | 2 channels for cascading of DS-KAD7060EY |
| Capacity | It can power up to 22 monitors with WiFi (DS-KH7300EY-WTE2) or 64 monitors without WiFi (DS-KH7300EY-TE2) It can power up to 16 minidistributors DS-KAD7061EY |
| Communication | Technology 2 HD wires (up to 6 devices) |
| Power | DC 48 V / 3.2 A max. |
| Temp. operation | -10º C ~ +55º C |
| Dimensions | 144 (W) x 92 (H) x 66 (D) mm |
| Weight | 250 g |
Power supply
DC output 48 V / 3.2 A / 150 W
2 outputs
178 (W) x 97 (H) x 38 (D) mm
DIN rail mount
Video intercom specific
Distributor for buildings
4 groups of 2 HD threads
Power up to 4 monitors of 2 HD threads
Power supply with DS-KAD7060EY or DS-KAD7061EY
Cascading of hubs
Size for standard gearbox
