Board and monitor | Allows up to 8 monitors more
Easy-to-configure firmware without network
Mobile App with P2P | Stainless Steel
Surface mounting | IP65, IK08
DS-KAD7060EY |
|
| Brand | Hikvision |
| Model | DS-KAD7060EY |
| Operation mode | Power, video and audio via 2 HD wire technology |
| Outputs | 2 channels of 2 HD threads with 15 W max. of power each 4 channels of 2 HD threads with 110 W max. of power between the four |
| Cascade | 2 channels for cascading of DS-KAD7060EY |
| Communication | Technology 2 HD wires (up to 6 devices) |
| Power | DC 48 V / 3.2 A max. |
| Temp. operation | -10º C ~ +55º C |
| Dimensions | 144 (W) x 92 (H) x 66 (D) mm |
| Weight | 250 g |
DS-KH7300EY-WTE2/White |
|
| Brand | Hikvision |
| Model | DS-KH7300EY-WTE2/White |
| Operating system | Linux |
| LCD | 7" color touch-screen TFT |
| Screen resolution | 1024 x 600 |
| Operation mode | Additional touch button panel: call initiation, call termination and door opening LED status indicator |
| Inputs | 1 x input of 2 HD wires, 1 x handheld headset |
| Outputs | 1 x output of 2 HD threads |
| Audio | Two-way audio with integrated microphone and loudspeaker Noise reduction and echo cancellation |
| Memory | MicroSD card slot (up to 128 GB) |
| Connection | 2 HD / RTSP / WiFi threads 802.11b/g/n (only for connection to app via P2P) |
| Remote access | Software iVMS-4200 Hik-Connect mobile application |
| Power | Through specific Hikvision hub for 2 HD wires (4 W max.) |
| Temp. operation | -10º C ~ +50º C |
| Dimensions | 138 (H) x 190 (W) x 20 (D) mm |
| Weight | 350 g |
| Colour | White |
| Slave monitors | It is not possible to use monitors that do not belong to the 2 HD thread system |
DS-KAW150-4N |
|
| Brand | Hikvision |
| Model | DS-KAW150-4N |
| Power supply input | AC 100~240 V / 1.8 A / 50/60 Hz |
| Power supply output | DC 48 V / 3.2 A |
| Voltage range | Adjustable 43.2~55.2 V |
| Maximum output power | 150 W |
| Number of outputs | 2 |
| Temp. operation | -10º C ~ +70º C |
| Dimensions | 178 (W) x 97 (H) x 38 (D) mm |
| Weight | 540 g |
DS-KD7003EY-IME2 |
|
| Brand | Hikvision |
| Model | DS-KD7003EY-IME2 |
| Operating system | Linux |
| Image sensor | Low Illumination 2 Mpx IR |
| Image Functions | BLC / WDR / DNR |
| Viewing angle | H: 133º, V: 82º |
| Audio | Bidirectional audio with microphone and speaker |
| Keypad | 2 x mechanical call button with LED customization tag |
| Outputs | 2 x locking relay (1 with DC 12 V / 500 mA), 1 x module output |
| Inputs | 2 x auxiliary inputs (exit button, door sensor), 1 x tamper |
| Remote access | Hik-Connect mobile application WiFi AP mode for configuration |
| Network interface | Network connection through 2 HD threads |
| Modular | Compatible with Hikvision modular boards |
| Power | DC 48 V with hub 2 HD wires DS-KAD7060EY / 12 V / 1700 mA max. |
| Degree of protection | Suitable for exterior IP65 Anti-vandal IK08 |
| Material | Plastic and stainless steel |
| Temp. operation | -40º C ~ +60º C |
| Dimensions | 98 (H) x 100 (W) x 35 (D) mm |
| Weight | 290 g |
