NVR-104S3-P4-ECO - Uniarch NVR Recorder
Uniarch NVR Recorder
4 CH video / 4 CH PoE
Bandwidth 64Mbps
SIP | UMD | VCA Search
Maximum resolution 6 Mpx
Supports 1 hard disk max. 6 TB
€50.00
(tax incl.)
DELIVERED IN: 2 to 5 days depending on destination country
Reference:
NVR-104S3-P4-ECO
Brand:
Add to compare0
Add to wishlist
| Brand | Uniarch |
| Inputs for IP cameras | 4 IP channels / 4 PoE channels |
| IP compatible cameras | UNIVIEW, ONVIF (Profile S, G, T) |
| Main Stream recording | 6Mpx / 5Mpx 4Mpx 3Mpx / 1080p / 960p 720p / D12CIF / CIF |
| Decoding | 2x6Mpx@ 30fps / 4x5MPx @ 30fps / 4x4MPx @ 30fps / 4x3MPx @ 30fps / 4x1080p @ 30fps |
| Bidirectional audio | 1 output 3.5 mm |
| Video outputs | 1 HDMI Full HD, 1 VGA simultaneous |
| Video compression format | Ultra H.265 / H.265 / H.264 |
| Display resolution | 1920x1080, 1600x1200, 1280x1024, 1280x720, 1024x768 |
| Total bandwidth | 64 Mbps downstream / 48 Mbps upstream |
| Intelligent functions from the camera | SIP: Intrusion detection, line crossing, area entry and area exit UMD (ultra motion detection) * You need an IP camera with these functions to be able to make configurations and searches from the recorder |
| VCA Search | Support |
| SIP (Smart Intrusion Prevention) from the camera | Supported in 4CH. Alarm reception only, no alarm image reception) * IP camera with SIP function required |
| External Backup | USB / HDD USB memory |
| Internal memory | 1 SATA HDD 3.5" of up to 6 TB (not included) |
| Communication | 2 x USB 2.0 / 1 x RJ45 (Ethernet) |
| Remote access | Web browser, Smartphone App & PC Software |
| Power | DC 48 V, <6W (No hard disk) |
| PoE port power supply | 30 W for a single port and 50 W in total |
| Operating temperature | -10ºC ~ +55ºC |
| Dimensions | 42 mm (H) x 190 mm (W) x 195 mm (D) |
| Weight | 1.0 Kg |
