Shelly Pro RGBWW PM DIN Rail LED Controller

The Shelly Pro RGBWW PM sets an advanced industrial benchmark for architectural and accent lighting automation inside electrical enclosures. Purpose-built for flawless physical integration on standard DIN rails, this micro-module features a robust 5-channel output topology. This custom-engineered hardware configuration gives system integrators full linear control over RGBWW (Red, Green, Blue, Warm White, and Cool White) LED arrays or complex color-temperature (CCT) lighting layouts, eliminating unstable light outputs, buzzing, or high-frequency strobe flicker.

The definitive reliability milestone of this professional device is the onboard physical LAN (Ethernet) port. This wired pipeline provides absolute network stability and complete immunity against radio frequency interference, making it an essential building block for hotels, workspaces, or luxury residential systems where low latency is mandatory. The module supports adaptive profile switching (CCT x2, RGB+CCT, RGB+2x Lights, or Lights x5), enabling users to even manage up to 5 completely independent single-color white LED channels from a single block. Note that it works strictly under direct current setups and cannot dim 230V legacy lines.

The integrated "PM" telemetry monitors voltage, current, and true active power simultaneously to generate accurate historical metrics and trigger advanced local JavaScript scripts. Built inside a premium flame-retardant (V-0) enclosure, it incorporates an internal thermal micro-sensor that scans every 100 ms to trip all outputs immediately if an overtemperature, overvoltage, or overcurrent event is flagged. Out of the box, the Shelly Pro RGBWW PM implements native compatibility with Home Assistant, MQTT, REST API, and Webhooks for high-tier professional installations.
