| Brand | Anviz |
| Activation sensor | Key-press |
| Keypad | Tactile |
| Capacity | Up to 10.000 users or cards |
| Records | Up to 200.000 |
| Identification modes | Password (4 - 6 digits) or card |
| Proximity card | EM RFID (125KHz) & MF (13,56MHz) |
| PC communication | TCP/IP, WiFI, Bluetooth, miniUSB and Wiegand |
| Inputs | Door sensor, push button, alarm output |
| Degree of protection | IP65, IK10 |
| Outputs | Wiegand, Output relay NO/NC |
| Software | CrossChex Standard: free local PC software for access and presence control CrossChex Mobile: free mobile application for access control |
| Power | DC 12 V |
| Dimensions | 22 (D) x 47 (W) x 124 (H) mm |
| Weight | 340 g |
