IPC-T134-AF28-DL-ECO - Uniarch Dual Light 4MP Turret IP Camera 2.8mm

IPC-T134-AF28-DL-ECO - Uniarch Dual Light 4MP Turret IP Camera 2.8mm

The IPC-T134-AF28-DL-ECO is a 4MP Uniarch Turret IP camera designed for professional video surveillance systems. It combines high-definition resolution, Dual Light technology and human body detection. This combination makes the camera suitable for different security applications, including homes, commercial premises, offices, warehouses, entrances and other indoor or outdoor areas.

Equipped with a 1/3" CMOS sensor, the camera provides a maximum resolution of 4MP (2560 × 1440). Its fixed 2.8mm lens provides a horizontal field of view of 87.8°. This configuration allows a wide area to be monitored and is particularly suitable for installations requiring a general overview of the protected area.

IPC-T134-AF28-DL-ECO with Dual Light technology

The IPC-T134-AF28-DL-ECO belongs to the Uniarch Dual Light range. This technology provides greater flexibility for video surveillance under different lighting conditions. Infrared illumination offers a maximum range of 30 m, allowing surveillance to continue at night or in environments with low ambient light.

The camera has a minimum illumination level of 0.01 Lux in colour and can operate at 0 Lux with infrared illumination active. A mechanical ICR filter provides switching between day and night operating modes.

4MP, 2.8mm lens and DWDR

The 4MP resolution of the IPC-T134-AF28-DL-ECO provides detailed images for IP security systems. Its fixed 2.8mm lens offers a horizontal field of view of 87.8°, vertical field of view of 48.9° and diagonal field of view of 99°. This configuration helps cover wide areas with a single Turret camera.

The DWDR function helps improve visibility in scenes with different lighting levels. The camera also features AGC, 2D/3D digital noise reduction, ROI, privacy masking and Smart IR. These functions help optimise the image according to the conditions present in the monitored area.

IPC-T134-AF28-DL-ECO with human body detection

The IPC-T134-AF28-DL-ECO incorporates human body detection, adding analytical capability to video surveillance events. This function helps the system identify events associated with human presence in the protected area.

The built-in microphone also enables audio capture within the monitored area. The system can therefore complement recorded images with audio information. This feature is useful for installations where audio capture forms part of the video surveillance solution.

PoE, ONVIF and Ultra 265 compression

Network connectivity is provided through an Ethernet 10/100 Base-T interface. The IPC-T134-AF28-DL-ECO supports ONVIF, API and SDK. This interoperability facilitates integration with compatible video surveillance equipment and platforms.

The camera uses PoE IEEE 802.3af, allowing electrical power and network data to be transmitted through compatible network infrastructure. This technology can simplify installation and reduce the amount of cabling required. The specified power consumption of the device is 2.5 W.

To optimise image transmission and storage, the IPC-T134-AF28-DL-ECO supports Ultra 265, H.265 and H.264 video compression. The camera does not feature internal storage or alarm inputs and outputs.

IPC-T134-AF28-DL-ECO with IP67 protection

The Turret housing of the IPC-T134-AF28-DL-ECO has an IP67 protection rating. This characteristic makes the camera suitable for both indoor environments and outdoor installations. Its operating temperature range extends from -30°C to 60°C.

The combination of 4MP resolution, a 2.8mm lens, Dual Light technology, IR illumination up to 30 m, human body detection, DWDR, a built-in microphone, PoE and ONVIF compatibility makes the IPC-T134-AF28-DL-ECO a versatile solution for professional IP video surveillance projects.
