IPC-B134-AF28-DL-ECO - Uniarch Dual Light 4MP Bullet IP Camera 2.8mm

IPC-B134-AF28-DL-ECO - Uniarch Dual Light 4MP Bullet IP Camera 2.8mm

The IPC-B134-AF28-DL-ECO is a 4MP Uniarch Bullet IP camera designed for professional video surveillance systems. It combines high-definition resolution, Smart Dual-Light illumination and Human Body Detection 2.0. These features make it suitable for monitoring homes, commercial premises, offices, warehouses, entrances and other indoor or outdoor areas.

The camera incorporates a 1/3" CMOS sensor and provides a maximum resolution of 4MP (2560 × 1440). Its fixed 2.8mm lens provides a horizontal field of view of 87.8°. This configuration allows the camera to monitor a wide area and makes it particularly suitable for installations requiring a general overview of the protected space.

IPC-B134-AF28-DL-ECO with Smart Dual-Light

One of the main features of the IPC-B134-AF28-DL-ECO is its Smart Dual-Light technology. This system combines infrared illumination with supplementary white light. The IR illumination provides a maximum range of 30 m, while the white light can reach up to 15 m.

The combination of these two illumination technologies provides greater flexibility in areas with little or no ambient light. The camera has a minimum illumination level of 0.01 Lux. It also incorporates a mechanical ICR filter for switching between day and night operating modes.

4MP, 2.8mm lens and DWDR

The 4MP resolution of the IPC-B134-AF28-DL-ECO provides detailed images for IP security systems. Its fixed 2.8mm lens offers a horizontal field of view of 87.8°, a vertical field of view of 48.9° and a diagonal field of view of 99°. This configuration helps cover wide areas with a single camera.

The DWDR function helps improve image visibility when different lighting levels are present within the same scene. The camera also provides image processing functions, including 2D/3D digital noise reduction and privacy masking. To optimise bandwidth usage, it supports Ultra 265, H.265 and H.264 video compression.

IPC-B134-AF28-DL-ECO with Human Body Detection 2.0

The IPC-B134-AF28-DL-ECO incorporates Human Body Detection 2.0. This function adds analytical capability to video surveillance events and helps identify events associated with human presence.

In addition to this function, the camera supports motion detection. Its built-in microphone allows audio to be captured in the monitored area. Audio can therefore provide additional information alongside the images recorded by the video surveillance system.

PoE, ONVIF and Ultra 265 compression

Network connectivity is provided through an Ethernet RJ45 10/100 Base-T interface. The IPC-B134-AF28-DL-ECO supports ONVIF, facilitating integration with compatible video surveillance equipment and platforms. It also supports API and SDK.

Power can be supplied through PoE IEEE 802.3af or 12 V DC. PoE allows electrical power and network data to be transmitted through compatible network infrastructure. This solution can simplify cabling in different professional installation projects.

IPC-B134-AF28-DL-ECO with IP67 protection

The Bullet housing of the IPC-B134-AF28-DL-ECO has an IP67 protection rating against water and dust ingress. This characteristic makes the camera suitable for both indoor environments and outdoor installations.

The combination of 4MP resolution, a 2.8mm lens, Smart Dual-Light, IR illumination up to 30 m and white light up to 15 m provides a versatile solution for different lighting conditions. Human Body Detection 2.0, DWDR, the built-in microphone, PoE and ONVIF compatibility complete the IPC-B134-AF28-DL-ECO for professional video surveillance projects.
