Uho-P2S-M55F34 - Uniarch 5MP+5MP Dual Lens PTZ WiFi IP Camera 2.8mm+4mm

Uho-P2S-M55F34 – Uniarch 5MP+5MP Dual Lens PTZ WiFi IP Camera 2.8mm+4mm

The Uho-P2S-M55F34 is a Uniarch PTZ WiFi IP camera designed for outdoor video surveillance systems. It integrates two cameras into a single device through a Dual Lens architecture. This configuration combines a fixed panoramic camera with a detail PTZ camera. It therefore provides a wide overview of the monitored area while allowing a specific zone to be observed with greater precision.

Both video channels use a single IP address, simplifying system integration and management. The camera uses 1/3.0" Progressive Scan CMOS sensors and provides a maximum resolution of 5MP (2880 × 1620). The Main Stream also supports 4MP, 3MP, 2MP and 720P resolutions at up to 15 fps.

The Uho-P2S-M55F34 supports Ultra 265, H.265 and H.264 video compression. These technologies help reduce bandwidth consumption and storage requirements while maintaining high image quality.

Uho-P2S-M55F34 Dual Lens with 2.8mm and 4mm lenses

The Uho-P2S-M55F34 combines a fixed panoramic 2.8mm lens with a 4mm detail PTZ lens. The panoramic lens provides a field of view of 94.9° horizontally, 53.7° vertically and 100.5° diagonally. This wide coverage makes it possible to monitor a large area while maintaining an overall view of the scene.

The PTZ channel uses a 4mm lens with a field of view of 80.6° horizontally, 44.8° vertically and 86.7° diagonally. This channel can be directed towards specific areas. It also provides 4X digital zoom to enlarge selected details during monitoring.

Motorized PTZ for targeted area monitoring

The panoramic camera allows Pan adjustment from -150° to 150° and Tilt adjustment from -5° to 30°. The detail PTZ camera provides Pan movement from 0° to 350° and Tilt movement from 0° to 90°. This combination offers flexible coverage and makes it possible to monitor different angles within the protected area.

The Dual Lens architecture reduces the need to install two separate cameras at the same location. While the panoramic channel maintains the general view, the PTZ camera can be directed towards specific points. The Uho-P2S-M55F34 also supports auto tracking, allowing the PTZ channel to follow a detected target.

Smart Dual Light with infrared and white light

The Uho-P2S-M55F34 features Smart Dual Light technology, combining infrared illumination and white light. On the panoramic channel, illumination reaches up to 10 metres. On the detail PTZ channel, the illumination range can reach up to 30 metres.

Minimum illumination is 0.003 lux in colour mode with F1.6 and AGC enabled, and 0 lux when IR is active. A mechanical ICR filter provides Day/Night switching. The camera also includes image enhancement technologies such as DWDR, Smart IR, AGC and 2D/3D noise reduction.

Uho-P2S-M55F34 with WiFi 6 and UMD

The WiFi connection operates on the 2.4 GHz band and supports IEEE 802.11b/g/n/ax standards. IEEE 802.11ax compatibility enables WiFi 6 operation when used with compatible networks. For wired installations, the camera also provides an RJ45 10/100 Base-TX Ethernet interface.

Among its intelligent functions, the camera includes UMD (Ultra Motion Detection). This technology helps improve the detection of relevant movement within the monitored area. The camera also supports motion detection, audio detection and tampering alarm.

In addition, the Uho-P2S-M55F34 provides intelligent human and vehicle detection. Auto tracking complements these functions by allowing the PTZ channel to follow a detected target. This combination is particularly useful for outdoor areas requiring active surveillance.

Two-way audio and MicroSD storage up to 512 GB

The Uho-P2S-M55F34 includes a built-in microphone and speaker for two-way audio. This makes it possible to listen to the monitored environment and communicate remotely through the camera. Audio compression supports G.711U and G.711A formats.

The camera also provides sound and light warning functions for active event signalling. For local storage, it includes a MicroSD card slot supporting capacities up to 512 GB. Recordings can therefore be stored directly on the device.

Uho-P2S-M55F34 with IP66 protection for outdoor use

The Uho-P2S-M55F34 has an IP66 protection rating, making it suitable for outdoor video surveillance systems. Its operating temperature ranges from -30 °C to 60 °C. The device also provides surge protection up to 4 kV.

Power is supplied through 12 V DC, with a maximum power consumption of 11.5 W. The camera measures Ø117 × 157 × 202 mm and weighs approximately 620 g. Its combination of Dual Lens 5MP+5MP, 2.8mm and 4mm lenses, PTZ, WiFi 6, Smart Dual Light, UMD, two-way audio, auto tracking and IP66 protection makes it a complete solution for outdoor video surveillance.
