Ajax Superior NVR H2DAI8PAC 16-Ch 8 PoE Black — 4K AI IP Recorder, 8 PoE+ Ports, Dual Hot-Swap HDDs & HDMI

Professional 16-Channel Black Ajax Superior NVR H2DAI8PAC IP Recorder with 8 PoE+ Ports, Onboard AI, and Dual Hot-Swap HDDs

The 16-Channel 8-PoE Black Ajax Superior NVR H2DAI8PAC belongs to Ajax Systems' flagship professional line. Indeed, this equipment is engineered for high-security projects requiring direct camera powering. The recorder features onboard Artificial Intelligence (AI) technology. Consequently, it upgrades third-party cameras with advanced smart analytics. The system delivers accurate detection of humans, vehicles, and pets on up to 12 simultaneous channels.

Furthermore, the device simplifies network infrastructure by integrating a built-in 8-port PoE/PoE+ switch (IEEE 802.3af/at) with a 200 W total PoE power. In this way, it powers and transmits data to 8 IP cameras over direct network cables, allowing additional cameras to be added over the local network (LAN). The unit also includes 1 dedicated Gigabit RJ-45 Ethernet uplink port (10/100/1000 Mbps). Bandwidth reaches 384 Mbps incoming and 384 Mbps outgoing. Likewise, it features support for 2 × 2.5" or 3.5" SATA hard drives up to 24 TB per drive (up to 48 TB total). The hot-swap capability allows drive replacement in real time without service interruption.

4K Local Display, Storage Modes, and JetSparrow Technology

For local monitoring, the Superior NVR H2DAI8PAC includes a 4K HDMI output (up to 3840 × 2160 px). Additionally, it features 3 USB ports (1 × USB 3.0 on front panel and 2 × USB 2.0 on rear panel). The unit manages up to 16 IP video channels via Ajax cameras or ONVIF and RTSP protocols. Therefore, it offers two advanced storage resiliency modes: Redundancy and Split.

Besides, video streaming and event log synchronization occur instantly. This is achieved through the proprietary P2P JetSparrow protocol. As a result, all data streams remain fully encrypted and secure against unauthorized access.

Professional Management via APP PRO and Top-Tier Cybersecurity

Engineered for certified installers, setup is managed via the APP PRO (Ajax PRO app). Thus, access permission management and remote maintenance are fast and efficient. The recorder includes an internal AC power supply with a maximum consumption of 280 W.

Finally, the unit meets strict international cybersecurity standards. Highlights include mTLS encryption and full NDAA compliance. For complete technical specifications, visit the official page for Ajax Superior NVR H2DAI8PAC (16-ch) on Ajax Systems.
