SD2A500NB-GNY-A-PV - 5MP Smart Dual Light IP PT Camera 4 mm

SD2A500NB-GNY-A-PV - 5MP Smart Dual Light IP PT Camera 4mm

The SD2A500NB-GNY-A-PV is a 5MP IP PT camera from Dahua, equipped with Smart Dual Light technology, Deep Learning-based Artificial Intelligence functions and an active deterrence system. With a fixed 4mm lens, Pan/Tilt movement, SMD 3.0, perimeter protection and two-way audio, it provides a complete solution for professional video surveillance systems.

High-quality 5MP resolution

The SD2A500NB-GNY-A-PV uses a 1/2.8" CMOS sensor with a maximum resolution of 2560 × 1920 (5MP). This resolution provides detailed images for residential, commercial and professional security applications.

4mm fixed lens

The fixed 4mm lens, with a maximum aperture of F1.6, provides a field of view of 80.4° horizontal, 58.1° vertical and 104.8° diagonal. A minimum focusing distance of 0.3 m provides good flexibility for different video surveillance scenarios.

PT movement with 300 presets

The SD2A500NB-GNY-A-PV provides horizontal Pan movement from 0° to 345° and vertical Tilt movement from 0° to 80°. It supports up to 300 presets, power-off memory and return to a preset position after inactivity.

Smart Dual Light with IR 30m and warm light 30m

Smart Dual Light technology combines IR illumination up to 30m and warm light up to 30m. The camera integrates two IR illuminators and two warm light illuminators to provide effective surveillance under low-light conditions.

AI and intelligent analysis

The SD2A500NB-GNY-A-PV uses AI and Deep Learning algorithms to improve event analysis and focus surveillance on relevant security targets.

SMD 3.0 and IVS perimeter protection

SMD 3.0 improves intelligent motion detection. The camera also features IVS functions such as intrusion and tripwire, strengthening perimeter protection for monitored areas.

Active deterrence with light and siren

The active deterrence function allows light and sound warnings to be triggered when an event is detected. The warm light can operate in flashing mode, and the camera also supports predefined or customised audible alarms.

Built-in two-way audio

The SD2A500NB-GNY-A-PV integrates a microphone and speaker, providing real-time two-way audio. This function makes it possible to listen to the monitored area and communicate directly through the camera.

Smart H.265+ and Smart H.264+

The camera supports Smart H.265+, H.265, Smart H.264+ and H.264, enabling more efficient use of bandwidth and storage space.

Micro SD up to 256 GB

The SD2A500NB-GNY-A-PV supports Micro SD cards up to 256 GB for local recording storage. It also supports storage via FTP.

Wired network connection, PoE and ONVIF compatibility

The camera uses a wired RJ-45 network connection and can be powered via 12 VDC or PoE 802.3af. With PoE, data and power can be transmitted through the same network cable. ONVIF Profile S and Profile T compatibility facilitates integration with different professional video surveillance systems.

Protection for professional installations

The SD2A500NB-GNY-A-PV is designed to operate between -30 °C and +55 °C and features protection against water, dust, overvoltage, electrical transients and lightning.
